Fluke 87V Industrial Multimeter

Key features

  • Identify complex signal problems fast
  • Supports accurate measurements on VFDs using a low-pass filter
  • Captures intermittents as fast as 250 µS with Peak Capture
Category:

Fluke 87V Industrial Multimeter







Product overview: Fluke 87V Industrial Multimeter

The Fluke 87V Industrial Multimeter provides the resolution and accuracy to efficiently troubleshoot motor drives, plant automation, power distribution, and electromechanical equipment – even in loud, high-energy, and high-altitude locations. The 87V is designed so you can work more efficiently.

  • Easy-access door for fast battery changes without breaking the calibration seal
  • Analog bar graph for fast changing or unstable signals
  • Large digit display with bright, two-level backlight for easier reading in low light
  • Touch Hold keeps readings on display even after removing probes

The 87V lets you identify complex electrical problems fast. It supports accurate measurements on VFDs using a low-pass filter. The meter also captures intermittents as fast as 250 µS using Peak Capture. High-frequency, high-energy noise generated by large drive systems is blocked from your measurements with specially designed shielding.

Built to highest safety standards

All the inputs in the 87V are updated to the third edition of the EN 61010-1 to CAT III 1000 V and CAT IV 600 V. The meter is designed to withstand spikes of more than 8000 V. You also benefit from an audible Input Alert warning if the test leads are placed in the incorrect input jacks for the measurement being made.

Removable holster with built in test lead and probe storage for convenience

The 87V has a removeable holster that also holds a test probe during testing for easier viewing. Relative mode lets you remove test lead resistance, improving accuracy of low-resistance measurements. To make your life even easier, the 87V fits into an optional magnetic hanger for easy set-up and viewing while freeing your hands for other tasks.



For a complete comparison of specifications, please visit our selection guide for digital multimeters.

Fluke 87V Industrial Multimeter Fluke 87V MAX True-rms Digital Multimeter Fluke 289 True-RMS Data Logging Multimeter Fluke 179 True-RMS Digital Multimeter Fluke 1587 FC Insulation Multimeter
CAT rating CAT III 1000 V
CAT IV 600 V		 CAT III 1000 V
CAT IV 600 V		 CAT III 1000 V
CAT IV 600 V		 CAT III 1000 V
CAT IV 600 V		 CAT III 1000 V
CAT IV 600 V
True-rms readings ✔ ✔ ✔ ✔ ✔
Voltage AC/DC 1000 V 1000 V 1000 V 1000 V 1000 V
Current AC/DC 10 A 10 A 10 A 10 A 400 mA
Resistance 50 MΩ 50 MΩ 500 MΩ 50 MΩ 50 MΩ
Capacitance 9,999 μF 9,999 μF 100,000 μF 9,999 μF 9,999 μF
Temperature -200 °C to 1090 °C -200 °C to 1090 °C -200 °C to 1350 °C -40 °C to 400 °C -40 °C to 537 °C
Additional
measurement
capabilities		 Frequency,
continuity/diode test,
motor drive (VFD)
measurement,
duty cycle,
microamps, analog
bar graph, relative
reference		 Conductance,
continuity/diode test,
duty cycle,
frequency, microamps,
motor drive (VFD)
measurement,
pulse width,
elative reference		 Conductance (50ns),
duty cycle,
frequency,
continuity/diode test,
low input
impedance,
microamps,
pulse width		 Continuity/diode test,
frequency,
microamps		 Frequency, Pi/DAR
timed ratio tests,
continuity/diode test,
motor drive (VFD)
measurement,
microamps, relative
reference
IP rating IP 30 IP 67 IP 42 – –
Battery life 400 hours 800 hours 200 hours 200 hours 1000 hours
Drop test 3 meters 4 meters – – –
Backlit keypad No Yes No No No
